Brand - McMASTER-CARR
Item Number - 3659K23 McMASTER-CARR
Category - Threaded Track Roller (Black-Oxide Steel Crowned Rollers with Seal)
Diameter of Roller (inch) - 1.875
Diameter of Roller (mm) - 47.625
Width of Roller (inch) - 1
Width of Roller (mm) - 25.4
Diameter of Stud (inch) - 0.75
Diameter of Stud (mm) - 19.05
Length of Stud (inch) - 1.75
Length of Stud (mm) - 44.45
Diameter of Thread (inch) - 0.75
Diameter of Thread (mm) - 19.05
Number of Threads per inch - 16
Length of Thread (inch) - 0.875
Length of Thread (mm) - 22.225
Diameter of Shoulder (inch) - 1.25
Diameter of Shoulder (mm) - 31.75
Shoulder Length (inch) - 0.79375
Shoulder Length (mm) - 20.16125
Maximum Speed (rpm) - 2000
Radial Static Load Capacity (lbs) - 7900
Radial Dynamic Load Capacity (lbs) - 6300
Maximum Temperature (°F) - 250°
Inside Bearing Type - Needle Roller
