Brand - McMASTER-CARR
Item Number - 1592T103 McMASTER-CARR
Category - Maintenance Free Threaded Track Roller (Steel Crowned Rollers with Seal)
Diameter of Roller (mm) - 40
Width of Roller (mm) - 20
Stud Diameter (mm) - 18
Stud Length (mm) - 36
Size - M18
Thread Diameter (mm) - 18
Thread Pitch (mm) - 1.5
Thread Length (mm) - 19
Shoulder Length (mm) - 0.8
Maximum Speed (rpm) - 550
Radial Static Load Capacity (lbs) - 5600
Radial Dynamic Load Capacity (lbs) - 3300
Maximum Temperature (°F) - 175°
Bearing Type - Needle Roller
Includes - Mounting Hardware

** Images are for representation purposes only
